EPW Series
Product Description
Reducing Tap Well permits a 200 A deadbreak or loadbreak tap-off of a 600A connector.
Technical Specification
| Rated voltage |
15/25kV ,35kV |
|---|---|
| Rated Current |
600A to 200A |
| Product Type Number |
EPW262 ,EPW362 |
| Product Category |
Reducing Tap Well |
Technical Specification
Special Description:
- Designed and manufactured in accordance with the requirements of IEEE Std 386TM-2016, standard for separable insulated connector systems. For external attachment and allow interchangeability with similarly designed bushings used on many types of pad-mounted transformers.
- Product manufactured with high quality epoxy material. Operational temperature withstand can be up to 150°C.
- Can be used with 200A Loadbreak or Deadbreak inserts.
Table 1 - Electrical Data
| Voltage Ratings | 15/25kV | 35kV |
| Operating Voltage | ||
| Maximum Phase-to-Phase | 28kV | 36.6kV |
| Maximum Phase-to-Ground | 16.2kV | 21.1kV |
| Withstand Voltage | ||
| AC: 60Hz, 60 Sec | 45kV | 50kV |
| DC: 15 Minutes | 100kV | 103kV |
| Impulse Voltage Withstand | ||
| BIL and Full Wave Crest | 125kV | 150kV |
| Corona Extinction Level | ||
| < 3pC (kV) | 21.5kV | 26kV |
| Continuous Current | 200Amp | |
| Short Time Current | 10kA sym. for 0.17s 35kA sym. for 3.0s | |
| Type Number | EPW262 | EOW362 |
Table 2 – Standard accessory attachment pack Information
| Type Number | Accessory | Qty |
| EPW262 | Silicone Lubricant Installation Instruction Sheet | 1 1 |
| EPW362 |
Note:
