Features
- EPR rubber laminated with self-fusion mastic rubber.
- Electrical insulation and impact resistant.
- Immediate bonding on splices or cable ends, provides absolutely water sealing properties.
- Application: 600V underground cable splice or joint: Duct or direct buried. Self-bonding to seal high voltage cable splice or joint, terminations, elbow connectors, etc. Sealing and insulating high voltage overhead connectors such as H or C type compression connectors. Bus bar insulation and oxidation protection, communication cable sealing and insulation.
Technical Data
| RMT-Electric Sealing Tape | |||||
|---|---|---|---|---|---|
| Electrical Ratings | Catalogue Number | ||||
| Voltage Class | 600VAC | ||||
| 60Hz AC Withstand | 25kV+ , 1min | RMT | Width (mm) | Length (cm) | Rolls/Carton |
| Insulation Resistance | 1x106MΩ+ | ||||
| Mechanical Ratings | 12 | 12.7 | 305 | 20 | |
| Color | Black | 19 | 19.1 | 305 | 20 |
| Elongation | > 800% | 25 | 25.4 | 305 | 20 |
| Breaking Strength | > 2 kgs | 38 | 38.1 | 305 | 20 |
| Adhesive | < 2 cm peel-off | 50 | 50.8 | 305 | 20 |
| Water Absorption < 0.2% | < 0.2% | Other sizes are available upon request. | |||
| Thinkness | 1.7mm ± 0.5mm | ||||
| Temp Rating | 90°C continuously | ||||
| Type Number | RMT12 / 19 / 25 / 38 / 50 | ||||
